    Wall Mounted Digital Ultrasonic Flow Meter DN80-DN200 4-20mA Relay Alarms Ultrasonic Depth Sensor

    AUF800 Digital Ultrasonic Water Flowmeter Wall Mounted DN80-DN200 4-20mA relay alarms/Ultrasonic Depth Sensor

    Product Description


    Digital Ultrasonic Water Flowmeter Wall Mounted DN80-DN200 4-20mA relay alarms can be virtually applied to a wide range of in long-term online measurement. Convertor protection class IP67, transducer protection class IP68. Avariety of liquid applications can be accommodated:ultra-pure liquids,portable water, chemicals, raw sewage, reclaimed water, cooling water, river water, plant effluent.etc




    Products name
    Digital Ultrasonic Water Flowmeter Wall Mounted DN80-DN200 4-20mA relay alarms
    Main unit
    Accuracy
    Better than ±1%
    Principle
    Transit-time measuring principle
    Measurement
    Period
    500ms
    Display
    LCD with backlight, display accumulated flow/heat, instantaneous flow/heat, velocity, time etc.
    Output
    Analogue output: 4-20mA or 0-20mA current output. Impedance 0∼1kW. Accuracy 0.1%.
    OCT output: Frequency signal (1~9999HZ)
    Relay output: over 20 source signal (no signal, reverse flow etc.)
    RS485 serial port
    Input
    Three analogue input
    Three-wire PT100 resistor input (optional)
    Pipe
    material
    Steel, stainless steel, cast iron, cement pipe, copper, PVC, aluminum, FRP etc. Liner is allowed
    Size
    15-6000mm
    Straight pipe section
    In the upstream it must be beyond 10D, in the downstream it must be beyond 5D, in the upstream the length must be beyond 30D from
    the access of the pump. (D stands for pipe diameter)
    Liquid
    Types
    Water, sea water, industrial sewage, acid & alkali liquid, alcohol, beer, all kinds of oils which can transmit ultrasonic single
    uniform liquid
    Turbidity
    Less than 10000ppm, with a little bubble
    Flow Direction
    Bi-directional measuring, net flow/heat measuring
    Power Supply
    AC220V or DC24V
